Description
Reinforced High Temperature & Chemical Resistant Rubber for Critical Applications
Viton A Insertion Rubber Sheet is a premium-grade Nomex-reinforced FKM (fluoroelastomer) rubber, engineered for extreme environments requiring maximum strength, dimensional stability, and chemical resistance.
With a hardness of 75 Duro and Nomex reinforcement, this material delivers superior tear strength and structural stability, making it ideal for high-stress, high-temperature, and chemically aggressive applications.
Designed for Extreme Industrial Conditions
SEC Business Group supplies advanced rubber solutions for mining, oil & gas, chemical processing, and heavy industrial environments.
Viton A Insertion Rubber Sheet is developed for critical sealing applications where conventional elastomers may fail due to temperature, chemical exposure, or sustained mechanical stress.
Features & Benefits
- Premium FKM (fluoroelastomer) rubber compound.
- Reinforced with high-strength Nomex fabric.
- Exceptional resistance to chemicals and aggressive acids.
- Excellent resistance to oils, fuels, and hydrocarbons.
- Performs in high-temperature environments up to +230°C.
- High tear strength and dimensional stability.
- Resistant to mineral acids, aliphatic and aromatic hydrocarbons.
- Excellent ozone and UV resistance.
- Maintains performance under extreme conditions.
- Suitable for high-load and high-stress applications.
- Available in sheet, strip, or custom-cut formats.
- Supplied by SEC Business Group.
Applications
- Flange gaskets on pipes and tanks
- Expansion joints
- Transfer and joining sleeves
- Chemical-proof flashing
- Insulating strips
- Isolation barriers
- Heavy-duty chemical sealing applications
- High-temperature sealing systems
- Applications requiring reinforced rubber stability
Performance Advantages
- Reinforcement prevents deformation under load and pressure.
- Designed for extreme chemical exposure and high temperatures.
- Maintains integrity in critical sealing environments.
- Ideal for long service life in harsh industrial conditions.
Technical Information
| Property | Value | Standard |
|---|---|---|
| Polymer | FKM | |
| Reinforcement | Nomex | |
| Fluorine Content | 66% (min) | |
| Specific Gravity | 1.85 | ASTM D297 |
| Hardness | 75° ± 5° Shore A | ASTM D2240 |
| Tensile Strength | 7 MPa (min) | ASTM D412 |
| Elongation @ Break | 175% (min) | ASTM D412 |
| Temperature Range | -10°C to +230°C |
Available Sizes
| Description | Weight (Per L/M) |
|---|---|
| Nomex Reinforced 1.5mm × 1200mm (10 L/M Rolls) | 3.5 kg |
| Nomex Reinforced 3mm × 1200mm (10 L/M Rolls) | 7 kg |
Custom Options
Viton A Insertion Rubber Sheet can be supplied as:
- Reinforced gaskets and pads
- Heavy-duty sealing components
- Chemical-resistant fabricated parts
- Custom-cut profiles
Supply
This product is supplied by SEC Business Group.
For material selection, engineering applications, or chemical compatibility advice, contact SEC Business Group.
