Mechanically Fastened Rubber Wear Plates
Premium 60 Duro Rubber Liners for Abrasion and Impact Protection
PT Rubber Wear Plates are premium-grade 60 Duro rubber liners engineered for abrasion protection and moderate impact resistance in demanding industrial applications.
Manufactured from a highly elastic premium rubber compound, these liners provide excellent resistance to sliding abrasion and large particle impact while helping protect steel surfaces in high-wear process environments.
Each plate is supplied with heavy-duty embedded aluminium T-tracks for added stability and secure mechanical fastening, allowing strong, efficient, and lightweight liner installation.
Designed for High Wear Applications
PT Rubber Wear Plates are ideal for mechanically fastened lining systems requiring strong wear resistance, impact energy absorption, and easy installation.
SEC Business Group supplies durable rubber wear liner systems designed to protect equipment, reduce maintenance, and improve service life in mining, quarrying, and mineral processing applications.
Features & Benefits
- Premium 60 Duro rubber compound based on SAR 60
- Excellent resistance to sliding abrasion and large particle impact
- Provides superior wear protection for industrial equipment
- Absorbs impact energy to reduce vibration
- Helps lower noise levels and dust emissions
- Heavy-duty embedded aluminium T-tracks provide added stability
- Lightweight design allows strong and easy mechanical fastening
- Suitable for high wear and moderate impact applications
- Custom cut and custom moulded options available
- Supplied by SEC Business Group
Applications
- Chutes and feed spouts
- Hoppers and surge bins
- Skips and flasks for underground mining
- Cyclones
- Feeders
- Screens
- Mills and scrubber mills
- Trunnions
- Dump truck bodies
- Conveyor transfer chutes and deflector plates
Performance Advantages
- Durable protection in high abrasion and moderate impact zones
- Reduces vibration, noise, and dust through impact energy absorption
- Embedded T-tracks allow efficient and secure liner installation
- Suitable for custom engineered liner systems across a wide range of equipment
Technical Information
| Property | Value | Standard |
|---|---|---|
| Polymer | NR/BR | |
| Colour | Black with aluminium tracks | |
| Specific Gravity | 1.10 | ASTM D297 |
| Hardness | 60° ± 5° Shore A | ASTM D2240 |
| Abrasion | 90 mm³ (max) @ 10N | ASTM D5963 |
| Tensile Strength | 20 MPa (min) | ASTM D412 |
| Elongation @ Break | 450% (min) | ASTM D412 |
| Temperature Range | -20°C to +70°C | |
| Tear Strength | 80 N/mm (min) | ASTM D624 |
Available Sizes
PT Rubber Wear Plates are supplied with embedded aluminium T-tracks designed to be fastened with T-Bolt assemblies.
| Description | Weight Each |
|---|---|
| PT Rubber Wear Plate 55mm x 600mm x 1000mm C/W 2 x AL-140 T-Tracks @ 300mm Centres | 40 kgs |
| PT Rubber Wear Plate 55mm x 600mm x 1500mm C/W 2 x AL-140 T-Tracks @ 300mm Centres | 60 kgs |
| PT Rubber Wear Plate 80mm x 600mm x 1000mm C/W 2 x AL-140 T-Tracks @ 300mm Centres | 60 kgs |
| PT Rubber Wear Plate 80mm x 600mm x 1500mm C/W 2 x AL-140 T-Tracks @ 300mm Centres | 90 kgs |
Technical drawings available on request.
Custom Options
- Custom cut wear panels
- Mechanically fastened liner systems
- Heavy-duty impact protection panels
- Custom moulded rubber liner solutions
- Application-specific wear packages
Supply
This product is supplied by SEC Business Group.
For liner selection, technical advice, or custom fabrication, contact SEC Business Group.
