Description
Food Grade Pulley Lagging for Hygienic Conveyor Applications
Lag FG (FDA) Sheet Lagging is a premium-grade food-safe rubber pulley lagging, designed to improve traction, reduce belt slippage, and protect pulley
shells in hygienic conveyor environments.
Manufactured from a specialised NR/NBR rubber compound, Lag FG provides excellent resistance to food-based greases, animal fats, and plant oils, making it ideal for use in food
processing applications.
Designed for Food Processing Environments
This product is tested and compliant with FDA 21 CFR 177.2600, ensuring suitability for repeated contact with dry, aqueous, and fatty food products.
SEC Business Group supplies food-grade conveyor solutions to support safe, reliable, and compliant operations across food processing industries.
Features & Benefits
- Food-grade rubber compliant with FDA 21 CFR 177.2600.
- Suitable for contact with dry, wet, and fatty food products.
- Resistant to animal fats, oils, and food-based greases.
- Improves pulley traction and reduces belt slippage.
- Diamond-profile surface enhances grip and water shedding.
- Helps prevent material build-up on pulleys.
- Supplied in sheet form for full pulley coverage.
- Features CN bonding layer for reliable cold bonding.
- Easy installation with no hot vulcanising required.
- Supplied by SEC Business Group.
Applications
- Food processing conveyors
- Packaging and production lines
- Drive, head, and tail pulleys
- Hygienic material handling systems
- Any application requiring food-grade compliant pulley lagging
Compliance
Lag FG Sheet Lagging conforms to:
- FDA 21 CFR 177.2600 – Rubber articles intended for repeated use
Note: In accordance with FDA requirements, finished rubber articles should be thoroughly cleansed prior to first use in contact with food.
Technical Information
| Property | Value | Standard |
|---|---|---|
| Polymer | NR/NBR | |
| Colour | White with CN bonding layer | |
| Specific Gravity | 1.15 | ASTM D297 |
| Hardness | 60° ± 5° Shore A | ASTM D2240 |
| Tensile Strength | 10 MPa (min) | ASTM D412 |
| Elongation @ Break | 500% (min) | ASTM D412 |
| Abrasion | 250 mm³ (max) @ 10N | ASTM D5963 |
| Tear Strength | 40 N/mm (min) | ASTM D624 |
| Temperature Range | -20°C to +70°C |
Design Features
- Diamond profile surface for improved traction
- Designed to shed water and contaminants
- Supplied in sheet roll format for efficient installation
- Ensures consistent contact and performance across pulley surface
Available Sizes
| Description | Weight (Per L/M) |
|---|---|
| 8mm × 1500mm (Mini Diamond Profile, 10 L/M Rolls) | 18.8 kg |
Installation
Lag FG Sheet Lagging is supplied with a CN bonding layer, allowing for:
- Fast and reliable cold bonding installation
- Strong adhesion to steel or rubber pulley surfaces
- Reduced downtime compared to hot vulcanising
Supply
This product is supplied by SEC Business Group.
For sizing, application advice, or pricing, please contact SEC Business Group.
