Description
Increased Carrying Capacity for Incline Conveyors
Conveyor Belt T-Cleats are premium-grade rubber cleats, designed to increase the carrying capacity of conveyor belts and improve material handling performance.
Manufactured from a durable rubber compound, T-cleats provide excellent resistance to abrasion and impact, ensuring long service life in demanding environments.
Improved Material Retention on Inclines
T-cleats are designed to be securely bonded to conveyor belt covers, forming a rigid structure that supports material movement, particularly on inclined conveyors.
By helping to retain material on the belt surface, they reduce rollback, improve conveyor efficiency, and minimise spillage in bulk material handling applications.
Applications
- Incline and steep-angle conveyors
- Bulk material handling systems
- Mining and quarrying operations
- Processing plants
- Any application requiring increased load capacity and material control
T-cleats are installed across the belt in strips to retain material and prevent rollback, making them ideal for conveyors transporting loose or bulk materials.
Features & Benefits
- Premium rubber compound for durability and strength.
- Excellent resistance to abrasion and impact.
- Designed for easy bonding to conveyor belts.
- Rigid profile maintains structural integrity under load.
- Suitable for inclined and high-capacity conveyors.
- Helps reduce material rollback and spillage.
- Good UV and ozone resistance for outdoor applications.
- Available in a range of profiles and sizes.
- Supplied by SEC Business Group.
Technical Information
| Property | Value | Standard |
|---|---|---|
| Polymer | SBR | |
| Colour | Black | |
| Specific Gravity | 1.37 | ASTM D297 |
| Hardness | 70° ± 5° Shore A | ASTM D2240 |
| Tensile Strength | 11 MPa (min) | ASTM D412 |
| Elongation @ Break | 245% (min) | ASTM D412 |
| Temperature Range | -20°C to +70°C |
Available Sizes
Conveyor Belt T-Cleats are available in standard roll lengths and can also be supplied in cut lengths to suit specific conveyor requirements.
| Part Number | Description | Weight (Per L/M) |
|---|---|---|
| CL25 | 25mm T-Cleat (50 L/M Rolls) | 0.5 kg |
| CL50 | 50mm T-Cleat (25 L/M Rolls) | 1.2 kg |
| CL75 | 75mm T-Cleat (20 L/M Rolls) | 1.7 kg |
Supply
This product is supplied by SEC Business Group.
For sizing, bonding advice, or pricing, please contact SEC Business Group.
