Description
Wear Protection and Sealing Solutions for Conveyor Loading Zones
Chute Skirt Liners are premium-grade wear-resistant and impact-resistant rubber liners, designed to protect conveyor loading zones and improve material containment.
Manufactured from a highly elastic 60 Duro rubber compound, these liners provide excellent resistance to sliding abrasion and large particle impact, making them ideal for demanding bulk material handling applications.
Improved Containment and Wear Protection
Installed at discharge points on conveyor chutes, skirt liners act as both a wear liner and sealing solution, protecting steel surfaces while reducing material spillage and dust emissions.
Their flexible rubber construction allows effective sealing against the conveyor belt, improving containment and reducing material loss.
Design & Installation
Chute Skirt Liners are designed for easy installation onto existing chute structures and skirt boards using mechanical fastening systems.
Steel Backing
- Vulcanised steel plate for maximum strength and stability
- Ideal for high-impact applications
Aluminium T-Track
- Lightweight design with embedded aluminium T-track
- Allows quick installation using T-bolt fastening
- Ideal for fast maintenance and replacement
Available configurations include:
- Single bevel edge
- Parallel bevels
- Opposite bevels for reversible use
Features & Benefits
- Premium 60 Duro rubber compound for durability and flexibility.
- Excellent resistance to abrasion and high-impact loading.
- Protects chute walls and skirt boards from wear.
- Bevelled edge design improves sealing against the conveyor belt.
- Reduces material spillage and dust emissions.
- Adjustable to create an effective containment seal.
- Available with steel backing or aluminium T-track systems.
- Suitable for heavy-duty and high-wear applications.
- Supplied by SEC Business Group.
Applications
- Conveyor loading chutes
- Transfer points
- Mining and bulk material handling
- Quarrying and mineral processing
- Dust control and material containment systems
Technical Information
| Property | Value | Standard |
|---|---|---|
| Polymer | NR/SBR | |
| Colour | Black | |
| Specific Gravity | 1.10 | ASTM D297 |
| Hardness | 60° ± 5° Shore A | ASTM D2240 |
| Abrasion | 90 mm³ (max) @ 10N | ASTM D5963 |
| Tensile Strength | 20 MPa (min) | ASTM D412 |
| Elongation @ Break | 450% (min) | ASTM D412 |
| Tear Strength | 80 N/mm (min) | ASTM D624 |
| Temperature Range | -20°C to +70°C |
Available Sizes
Chute Skirt Liners are custom engineered to suit your application and can be:
- Cut to any profile
- Manufactured to drawings
- Supplied ready for installation
- Designed for easy maintenance
Supply
This product is supplied by SEC Business Group.
For sizing, design assistance, or pricing, please contact SEC Business Group.
