Description
Wear Resistant Rubber Lining for Abrasion and Corrosion Protection
40 Lining Rubber is a premium-grade 40 Duro natural rubber lining engineered for abrasion and corrosion protection in demanding industrial applications.
Manufactured from a highly elastic premium natural rubber compound, this lining provides excellent resistance to both wet and dry fine particle sliding abrasion. Reinforcing fillers improve resistance to cutting and gouging by sharp particles, making it well suited to harsh mineral processing environments.
The material features a specially formulated Neoprene-based CN bonding layer, designed to provide strong adhesion when bonded to steel or rubber surfaces using standard Neoprene-based rubber adhesives.
Designed for Abrasion, Cutting and Corrosion Resistance
SEC Business Group supplies durable lining materials designed to protect equipment surfaces, extend service life, and reduce maintenance costs in abrasive operating conditions.
40 is ideal for applications requiring a flexible wear-resistant rubber lining with strong bonding performance and additional protection against cutting and gouging.
Features & Benefits
- Premium natural rubber compound (NR).
- Excellent resistance to wet and dry fine particle sliding abrasion.
- Reinforcing fillers improve resistance to cutting and gouging.
- Very flexible with excellent physical properties.
- Strong cut and tear resistance.
- Resistant to some mild chemicals including acids and alkalis.
- Specially formulated Neoprene-based CN bonding layer.
- Compatible with a wide range of Neoprene-based rubber adhesives.
- Achieves strong bond strength even in adverse site conditions.
- Designed for long-term wear and corrosion protection.
- Available in sheets, strips, pads, and custom-cut components.
- Supplied by SEC Business Group.
Applications
Industrial Equipment Lining
- Chutes
- Tanks and pipework
- Cyclones
- Launders
- Flotation cells
- Screen components
- Trommels
- Conveyor pulleys and idlers
- Magnetic separator conveyor belts
General Wear Protection
- Mill seals
- Loading and discharge socks
- Transfer and joining sleeves
- Wear curtains
- Premium skirting rubber
- Variety of sealing applications
Performance Advantages
- Excellent wear resistance in both wet and dry fine abrasion conditions.
- Improved cutting and gouging resistance from reinforcing fillers.
- Flexible for easier installation and surface conformity.
- Strong bonding performance with CN bonding layer.
Technical Information
| Property | Value | Standard |
|---|---|---|
| Polymer | NR | |
| Colour | Orange with CN bonding layer | |
| Specific Gravity | 1.08 | ASTM D297 |
| Hardness | 40° ± 5° Shore A | ASTM D2240 |
| Tensile Strength | 20 MPa (min) | ASTM D412 |
| Elongation @ Break | 600% (min) | ASTM D412 |
| Abrasion | 85 mm³ (max) @ 5N | ASTM D5963 |
| Temperature Range | -20°C to +70°C | |
| Tear Strength | 45 N/mm (min) | ASTM D624 |
Available Sizes
40 Lining Rubber is stocked in a range of standard thicknesses and roll sizes. It can also be supplied in cut lengths, strips, pads, and a wide variety of custom-cut shapes and gaskets to suit your application requirements.
| Description | Weight (Per L/M) |
|---|---|
| 40 with CN B/L 3mm x 1500mm (10 L/M Rolls) | 6.2 kgs |
| 40 with CN B/L 6mm x 1500mm (10 L/M Rolls) | 10.7 kgs |
| 40 with CN B/L 6mm x 2000mm (10 L/M Rolls) | 14.2 kgs |
| 40 with CN B/L 10mm x 1500mm (10 L/M Rolls) | 16.5 kgs |
| 40 with CN B/L 10mm x 2000mm (10 L/M Rolls) | 22 kgs |
| 40 with CN B/L 12mm x 1500mm (10 L/M Rolls) | 20.7 kgs |
| 40 with CN B/L 12mm x 2000mm (10 L/M Rolls) | 27.6 kgs |
| 40 with CN B/L 20mm x 1500mm (10 L/M Rolls) | 33 kgs |
Custom Options
40 Lining Rubber can be supplied as:
- Equipment lining systems
- Custom wear panels
- Pipe and chute linings
- Flexible wear curtains
- Premium skirting components
- Engineered lining solutions
Supply
This product is supplied by SEC Business Group.
For technical advice, installation guidance, or custom fabrication, contact SEC Business Group.
